C++ Low-Latency, Enforced: __builtin_*, Compiler Flags, and clang-tidy, Benchmarked

The last post was about which C++ low-latency patterns actually reproduce on a modern CPU. Fifteen techniques from Bilokon & Gunduz’s HFT paper, Jonathan Müller’s Cache-Friendly C++ deck, and Okade & Baker’s C++ Performance Tips deck, all run through nanobench and published as working Godbolt links with measured ns/op numbers. Three of them didn’t reproduce. Twelve did.

This post is the sequel. The first post asked which patterns work. This post asks how do you make them mandatory — how do you pick them up automatically, reject their violations at review time, and catch the regressions in CI?

The answer sits in three concentric rings:

1. __builtin_* intrinsics. Code-level opt-ins. One programmer writes __builtin_popcountll(x) and the compiler emits a single CPU instruction. Same for __builtin_bswap64, __builtin_unreachable, __builtin_prefetch, the [[likely]] / [[unlikely]] attributes. They are the vocabulary the compiler expects when you want specific codegen.
2. Compiler flags. Project-level. -march=x86-64-v3 gives the whole binary AVX2; -ffast-math lets the compiler associate floating-point reductions; -Wpessimizing-move turns one class of perf bug into a build failure.
3. clang-tidy checks. Team-level guardrail. performance-for-range-copy, performance-unnecessary-value-param, modernize-use-emplace — the checks that catch the patterns from post 1 the moment someone violates them in a PR.

Seven new nanobench files, one .clang-tidy config, one CMake stanza. Numbers from the same GCC 14 -O2 -std=c++23 on the same desktop. Same Docker harness, same make_godbolt_nb.sh shortener pipeline. Two of the new benchmarks produced honest null results. One exposed a codegen regression at -march=x86-64-v3 that -O3 fixed. The rest are clean wins.

Part 1: __builtin_* — the low-level toolkit

Every GCC/Clang __builtin_* is a hand-shake with the compiler: I know the CPU has a one-instruction way to do this, please emit it. Some map to a single instruction (popcount, bswap, clz); some change codegen downstream by removing a branch (unreachable, expect); some are purely compile-time (constant_p, types_compatible_p). The four benchmarks below cover the four most useful categories.

1.1 __builtin_popcountll — 24× over a naive bit count

Counting the set bits in a 64-bit integer. The naive version is a loop over 64 bit positions; the classic “Kernighan’s trick” is while (x) { x &= x - 1; ++c; } which only iterates once per set bit. The intrinsic, on any POPCNT-capable CPU (every x86-64 in the last decade), lowers to one popcntq instruction.

static int popcount_naive(std::uint64_t x) {
  int c = 0;
  for (int i = 0; i < 64; ++i) c += (x >> i) & 1;
  return c;
}
static int popcount_kernighan(std::uint64_t x) {
  int c = 0;
  while (x) { x &= x - 1; ++c; }
  return c;
}
// __builtin_popcountll(x) — one instruction

Run over 64K random uint64_ts:

Godbolt: godbolt.org/z/rxfG5TjjG

naive 64-bit loop                           1,698,193 ns/op
Kernighan's trick (x &= x - 1)                918,384 ns/op   1.85×
__builtin_popcountll (one CPU instruction)     71,416 ns/op   23.8×

23.8× over the naive loop, 12.8× over Kernighan. __builtin_popcountll is the single biggest bang-for-buck intrinsic on x86-64, and yet I still see custom bit-count loops in production code because people forget it exists.

Its siblings deserve a line: __builtin_clzll(x) counts leading zeros (= 63 - log2(x) for non-zero x), __builtin_ctzll(x) counts trailing zeros, __builtin_ffsll(x) finds the lowest-set bit (1-indexed). All three lower to one instruction on modern x86 (lzcnt, tzcnt, bsf). The C++20 <bit> header wraps them as std::popcount, std::countl_zero, std::countr_zero, std::bit_floor — the standard-library names if you want them.

When to use: hash computation, population-count-based similarity, bitmap iteration, log2/align-up math. When not to: if your bitset is larger than 64 bits, use std::bitset::count() — libstdc++ routes through __builtin_popcountll in a loop, and the abstraction is free.

1.2 [[likely]] / [[unlikely]] — an honest null result

The C++20 attributes were supposed to finally standardise the __builtin_expect hint. On an error-check branch where the error fires 1% of the time, [[unlikely]] on the error path should move the cold block off the hot i-cache line and speed up the loop.

__attribute__((noinline)) static int process_none(int x) {
  if (x < 0) return -x;
  return x * 3;
}
__attribute__((noinline)) static int process_likely(int x) {
  if (x < 0) [[unlikely]] return -x;      // truth: only 1% are negative
  return x * 3;
}
__attribute__((noinline)) static int process_wrong(int x) {
  if (x < 0) [[likely]] return -x;        // lies to GCC — most x are >= 0
  return x * 3;
}

Godbolt: godbolt.org/z/W9bjaE6rP

no hint                                         532,965 ns/op
[[unlikely]] on the rare branch (correct)       545,022 ns/op    0.98×
[[likely]] on the rare branch (wrong hint)      522,675 ns/op    1.02×

All three are within 2% of each other — noise. Including the deliberately wrong hint. The branch predictor learns the pattern after the first handful of iterations and dispatches correctly regardless of what the attribute says. The hint does move the cold block in the emitted code, but the function body is so small that it fits entirely in L1i no matter the layout, so the move is a no-op.

When [[likely]] / [[unlikely]] actually pays:

• The cold branch contains a lot of code (logging, error formatting, metric emission) that would otherwise inflate the hot loop’s i-cache footprint.
• The hot function is large enough that i-cache pressure matters in aggregate, even if any one call site doesn’t spill.
• Profile-guided optimisation (PGO) isn’t available — with -fprofile-use, the compiler has real branch frequencies and the attributes become redundant.

Rule I apply: reach for [[unlikely]] only on error-handling / logging paths with non-trivial body size, or on paths the predictor can’t learn because the input distribution is adversarial. On a two-instruction branch, the attribute is documentation at best.

1.3 __builtin_unreachable() in a switch default — 1.55×

The counter-case to the honest null above. When you genuinely know a point in control flow is unreachable — for instance, a switch on an enum whose input is validated upstream — telling the compiler lets it drop bounds checks and emit a denser dispatch table.

enum class Op : int { Add = 0, Sub = 1, Mul = 2, Xor = 3 };

static int apply_safe(Op op, int a, int b) {
  switch (op) {
    case Op::Add: return a + b;
    case Op::Sub: return a - b;
    case Op::Mul: return a * b;
    case Op::Xor: return a ^ b;
  }
  std::abort();   // defensive default — keeps a branch live
}

static int apply_unreachable(Op op, int a, int b) {
  switch (op) {
    case Op::Add: return a + b;
    case Op::Sub: return a - b;
    case Op::Mul: return a * b;
    case Op::Xor: return a ^ b;
  }
  __builtin_unreachable();   // compiler assumes this point is never reached
}

Input: 1 M random Op values drawn uniformly from {0, 1, 2, 3}.

Godbolt: godbolt.org/z/srsGxEEhv

switch with std::abort() default              6,347,288 ns/op
switch with __builtin_unreachable() default   4,102,408 ns/op    1.55×

1.55× speedup. The std::abort version forces the compiler to keep a bounds check and an out-of-band call site live; the unreachable version drops both, and GCC collapses the switch into a four-entry jump table with no range check.

The C++23 replacement is std::unreachable() — same semantics, standard name. Use it over the builtin when you can.

Footgun warning: __builtin_unreachable is undefined behaviour if the compiler can actually reach it. If your enum has a fifth value silently added later and you don’t update the switch, you get silent UB — a wrong result, a memory-corruption crash, or a trap, depending on the compiler’s mood. Pair it with an assertion in debug builds: #ifdef NDEBUG __builtin_unreachable(); #else std::abort(); #endif or, better, a -Wswitch / -Wswitch-enum that fails the build if a case is missing.

1.4 __builtin_bswap64 — the idiom GCC already recognises

Flipping the endianness of a 64-bit integer is a one-instruction job on x86 (bswap). The portable idiom is eight shift-and-or operations:

static std::uint64_t bswap_portable(std::uint64_t x) {
  return ((x & 0x00000000000000ffull) << 56)
       | ((x & 0x000000000000ff00ull) << 40)
       | ((x & 0x0000000000ff0000ull) << 24)
       | ((x & 0x00000000ff000000ull) <<  8)
       | ((x & 0x000000ff00000000ull) >>  8)
       | ((x & 0x0000ff0000000000ull) >> 24)
       | ((x & 0x00ff000000000000ull) >> 40)
       | ((x & 0xff00000000000000ull) >> 56);
}

vs __builtin_bswap64(x). Iteration over 64K random uint64_ts:

Godbolt: godbolt.org/z/Pfbja61Eb

portable shift-and-OR expression     28,623 ns/op
__builtin_bswap64 (one instruction)  28,801 ns/op    0.99×

Identical. GCC has recognised the shift-and-or bswap idiom since version 4.8 (2013) and folds it to the same bswap instruction. So the intrinsic is — for this exact idiom on modern GCC — a wash.

It still matters in three ways:

• Clarity. __builtin_bswap64(x) says byte-swap a 64-bit integer. The 8-line portable version says please audit me for off-by-one shift errors.
• Portability across compilers. MSVC has _byteswap_uint64; Clang has __builtin_bswap64; GCC has it too. C++23 finally added std::byteswap. Before that, the platform define-dance is unavoidable.
• Version-of-compiler robustness. The idiom recognition is a pattern match; it breaks if you write the expression slightly differently. The intrinsic is guaranteed.

Same story for __builtin_bswap16 (→ xchg or rol 8) and __builtin_bswap32. C++23: use std::byteswap and let the standard library worry about which builtin to call.

1.5 Three more builtins that don’t need a benchmark

Runtime speed isn’t the only thing builtins unlock. Three worth knowing, none with a measurable runtime delta in my harness but all with a clear codegen or correctness payoff:

__builtin_assume_aligned(p, 64) tells the compiler the pointer is aligned to a 64-byte boundary, which lets the auto-vectoriser emit aligned loads/stores instead of unaligned ones. On recent Intel, aligned and unaligned loads have the same throughput when the address is actually aligned, so the runtime effect is zero — but on strict-alignment ARM targets, and on older x86, it is the difference between a single load and a split pair of loads. Use it on SIMD-sized inputs you control the allocation of.

__builtin_prefetch(addr, rw, locality) — covered in post 1’s §7. TL;DR: 20% win on a 1M-node pointer chase; marginal or negative on anything the hardware prefetcher can predict.

__builtin_constant_p(x) returns true inside the compiler when x is a compile-time constant, false otherwise. Used to pick between a cheap compile-time specialisation and a generic runtime path inside a macro. You won’t see it in modern C++ much — if constexpr and concepts do the job better — but glibc’s strcpy / memcpy / strlen still branch on it to emit a rep movs for small literal sizes vs a generic loop for variable ones. Handy if you’re writing header-only libraries that want to specialise on literal arguments.

Other builtins you’ll see in real codebases: __builtin_trap() (unconditional fault — smaller code than abort()), __builtin_assume(cond) (Clang-only; a __builtin_unreachable gated by cond), __builtin_FILE() / __builtin_LINE() / __builtin_FUNCTION() (pre-C++20 std::source_location), __builtin_types_compatible_p(T1, T2) (legacy type equality, obsoleted by std::is_same_v).

1.6 The canonical C++20 / C++23 alternatives

Every builtin above (and most of the ones this post doesn’t benchmark) has a standard-library wrapper in recent C++. On libstdc++ the std:: name is a one-line constexpr function that routes straight to __builtin_popcountll / __builtin_clzll / __builtin_bswap64 / etc. So the runtime and the emitted assembly are identical — the only reason to use the builtin by name is if you’re targeting a pre-C++20 standard or a compiler that hasn’t shipped <bit> yet.

Proof that the codegen matches (same input, three pairs of benchmarks):

Godbolt: godbolt.org/z/o4be6z4E7

__builtin_popcountll               72,372 ns/op
std::popcount  (C++20 <bit>)       72,116 ns/op    1.00×
__builtin_bswap64                  15,195 ns/op
std::byteswap  (C++23 <bit>)       14,406 ns/op    1.05×
__builtin_clzll                    20,030 ns/op
std::countl_zero  (C++20 <bit>)    19,888 ns/op    1.01×

Every std:: pair is within 1% of its builtin. Use the standard names.

The full mapping:

Three notes on picking between the two styles:

• MSVC portability is the main reason. __builtin_popcount doesn’t compile on MSVC; MSVC offers __popcnt64 with subtly different semantics. std::popcount compiles everywhere and routes to whatever primitive the backend has.
• constexpr-ness is free on the std:: names. std::popcount, std::countl_zero, std::byteswap, std::unreachable are all constexpr — you can use them in static_assert, in template non-type parameters, in if constexpr branches. The builtins accept compile-time args but the standard wrappers are cleaner about the boundary.
• C++23 is the cut-off for std::byteswap and std::unreachable. If your toolchain is stuck on C++20 (still common in 2026 for conservative deployments), use the builtins for those two. Everything else in the table is C++20.

The pattern I follow in new code: always start with the std:: name. Fall back to the builtin only if the compiler rejects it. Add a one-line #ifdef __cpp_lib_bitops / #ifdef __cpp_lib_byteswap wrapper at the top of a compat header if I need to straddle an older standard.

Part 2: Compiler flags that change everything

The intrinsic is a sentence; the flag is a paragraph. Flags are the project-level knobs that shift what the optimiser is willing to do across the whole binary. The two that move the most wall time on a compute loop are -march and -ffast-math. The ones that catch the most bugs at compile time are the -W family.

2.1 Optimisation levels — the ladder

Quick reminder on what each -O level unlocks:

-O2 is the right default for 95% of code. -O3 is not always faster — it increases inlining and unrolling, which can overflow the i-cache on larger binaries. Profile before committing.

2.2 -march and the x86-64 microarchitecture levels

By default, GCC targets the lowest-common-denominator x86-64 ISA — SSE2, no AVX, no BMI. On any desktop or server CPU made since 2013, you are leaving a lot of silicon idle.

The four x86-64-v* levels (introduced in GCC 11) give a portable way to dial in a feature set without pinning to a specific CPU:

Benchmark: auto-vectorisable 5-term polynomial eval over a 4 KiB (L1-resident) float array. Same source, three builds:

float s = 0.f;
for (int i = 0; i < N; ++i) {
  float x = a[i], y = b[i];
  float p = ((((x * 0.1f + y) * 0.2f + x) * 0.3f + y) * 0.4f + x) * 0.5f + y;
  s += p;
}

Two surprises:

1. -O3 -march=x86-64-v3 without -ffast-math is slower than -O2 baseline. Without -ffast-math, the compiler cannot associate the s += p reduction, so the whole loop stays sequential. AVX2 doesn’t help a sequential reduction; it does help emit FMA instructions for the polynomial, which GCC schedules onto execution ports in a way that turns out to be worse than the scalar sequence on my Intel. This is a real codegen regression on GCC 14 for this kernel. -O3 -march=native produced unstable timings too (41% error bar). -march=native is not a free speedup.
2. Add -ffast-math and AVX2 unlocks: now the reduction vectorises (sum 8 floats per cycle), and you get a clean 6.9× over -O2. That is the real floating-point-SIMD payoff.

The rule that survives this: enable -march=x86-64-v3 or -march=x86-64-v4 when your deployment targets are modern (most servers and workstations since 2014), but always pair it with -O3 and measure. The default x86-64 target gives you SSE2; leaving that on a server benchmark is the biggest single-flag leak I see.

2.3 -ffast-math — why the 2× ships with a warning

From the benchmark above, one-dimensional view: -O3 vs -O3 -ffast-math on a sum of 1 M doubles.

Godbolt: godbolt.org/z/osMTbGsWv (no ffast) vs godbolt.org/z/ocb9fEq5r (ffast)

-O3                 454,328 ns/op
-O3 -ffast-math     229,697 ns/op    1.98×

2× speedup from a single flag. Why it isn’t on by default: -ffast-math turns on six sub-flags, the most dangerous being -fassociative-math (sums can reorder), -ffinite-math-only (assume no NaN/Inf), and -fno-signed-zeros (treat -0 == 0). In a trading system where nan is a legitimate “no quote” value, or where a price-change log sums to a running total and must match to the cent across two replicas, these assumptions are catastrophic.

Use -ffast-math on compute kernels where:

• Inputs are bounded and free of NaN/Inf by construction.
• Associativity of floating-point sums is safe (you accept per-run rounding noise).
• The kernel is isolated — you can flag-switch it without flooding the rest of the binary with the new assumptions.

GCC 13+ offers -fassociative-math and the other sub-flags individually, so you can take the specific reordering permission without the full bundle.

2.4 -fno-exceptions / -fno-rtti — the Chromium defaults

Two flags that sound scary and aren’t: -fno-exceptions drops the exception-handling tables and throw support; -fno-rtti drops typeid and dynamic_cast. Chromium and LLVM both ship with both disabled by default. The runtime speed gain on well-inlined code is small (a few % in my measurements); the binary size gain is 10–25%, and the i-cache pressure reduction that implies can dominate the speed story on larger binaries.

The catch: std::vector<T> will still call __throw_bad_alloc on OOM, which becomes std::terminate under -fno-exceptions. If your code relies on exceptions for anything other than allocation failure, audit before switching. And a library compiled with exceptions enabled can’t reliably be linked against code compiled with them disabled — the ABI for stack unwinding differs.

2.5 Warnings that catch perf bugs

From Okade & Baker’s deck (covered in post 1), the warning flags that specifically catch the patterns that post measured:

Add them all to your -Wall -Wextra -Werror stack. They catch at compile time exactly the patterns that post 1’s benchmarks measured at run time. Every warning is a PR that doesn’t land with the bug.

Part 3: clang-tidy — enforce the patterns in CI

The warning flags above are gcc/clang’s built-in diagnostics. clang-tidy is a separate static analyzer that ships with LLVM, runs over your whole codebase, and has ~400 named checks. For post 1’s patterns, the relevant checks fall into three families.

3.1 The performance-* checks you actually need

From the CppCon 2025 deck — the minimum set that catches the common perf regressions:

3.2 performance-for-range-copy — the 41× benchmark

The clearest of the bunch. A range-based for over std::vector<std::string> that binds each element by value instead of const auto&.

static const auto names = make_names();  // 10,000 strings, each > SSO

// Silent copy per iteration — each std::string allocates on the heap
std::size_t total = 0;
for (auto x : names) total += x.size();

// No copy — just a reference
std::size_t total = 0;
for (const auto& x : names) total += x.size();

Godbolt: godbolt.org/z/rox1xc76T

for (auto x : names)  — copies each string         88,654 ns/op
for (const auto& x : names)  — no copy              2,169 ns/op    40.9×

40.9× real runtime cost. That is 10,000 heap allocations per iteration × millions of iterations in aggregate. The mistake shows up in every junior-to-mid-level C++ codebase I have reviewed. clang-tidy --checks=performance-for-range-copy flags it with:

warning: loop variable is copied but only used as const reference;
consider making it a const reference [performance-for-range-copy]
    for (auto x : names) total += x.size();
         ^
         const &

Turn that into -warnings-as-errors=* and the PR doesn’t merge.

3.3 A .clang-tidy you can drop in

Place at the root of your repo. Runs automatically when the editor or CI invokes clang-tidy.

---
Checks: >
  -*,
  bugprone-*,
  -bugprone-easily-swappable-parameters,
  -bugprone-exception-escape,
  cppcoreguidelines-pro-type-cstyle-cast,
  cppcoreguidelines-pro-type-member-init,
  cppcoreguidelines-slicing,
  misc-const-correctness,
  misc-definitions-in-headers,
  misc-unused-parameters,
  misc-use-anonymous-namespace,
  modernize-*,
  -modernize-use-trailing-return-type,
  -modernize-avoid-c-arrays,
  performance-*,
  readability-identifier-naming,
  readability-redundant-*

WarningsAsErrors: 'performance-*,bugprone-*,modernize-use-emplace,modernize-pass-by-value'

HeaderFilterRegex: '.*'

CheckOptions:
  - key: modernize-use-nullptr.NullMacros
    value: 'NULL'
  - key: readability-identifier-naming.ClassCase
    value: CamelCase
  - key: readability-identifier-naming.FunctionCase
    value: lower_case
  - key: readability-identifier-naming.VariableCase
    value: lower_case

Three notes:

• Starting with -* and enabling specific families is easier to maintain than “everything except some exclusions.” clang-tidy ships hundreds of checks; whitelisting is saner.
• WarningsAsErrors is the enforcement mechanism. Without it, clang-tidy prints warnings that everybody ignores. With it, the performance and bugprone checks are a CI gate.
• -modernize-use-trailing-return-type and -modernize-avoid-c-arrays are the two checks I always turn off — they’re style preferences that don’t reflect real-world C++ idioms.

3.4 Wiring clang-tidy into CMake

Two lines in your top-level CMakeLists.txt:

find_program(CLANG_TIDY_EXE clang-tidy REQUIRED)
set(CMAKE_CXX_CLANG_TIDY
    ${CLANG_TIDY_EXE}
    -warnings-as-errors=*
    --extra-arg=-std=c++23)

CMake then invokes clang-tidy as part of every add_library / add_executable target’s compile step. No .tidy targets to add; no custom commands. The --extra-arg=-std=c++23 line is important — clang-tidy parses your sources with its own Clang frontend and needs to be told the language mode.

To opt specific targets out (e.g., third-party dependencies pulled in as source), clear the variable per-target:

add_library(third_party_thing STATIC vendor/foo.cpp)
set_target_properties(third_party_thing PROPERTIES CXX_CLANG_TIDY "")

3.5 The GitHub Actions job

A minimal workflow that runs the whole lint in parallel with the build:

name: clang-tidy
on: [pull_request]

jobs:
  lint:
    runs-on: ubuntu-24.04
    steps:
      - uses: actions/checkout@v4
      - name: Install clang-tidy
        run: sudo apt-get update && sudo apt-get install -y clang-tidy-19
      - name: Configure
        run: cmake -B build -DCMAKE_EXPORT_COMPILE_COMMANDS=ON
      - name: Run clang-tidy
        run: |
          git diff --name-only --diff-filter=AM origin/main...HEAD \
            | grep -E '\.(cpp|h|hpp)$' \
            | xargs -r clang-tidy-19 -p build --warnings-as-errors=*

The git diff --name-only trick runs clang-tidy only on files changed in the PR, not the whole tree — which keeps the lint step under a minute on even large codebases. For a full-tree check, run clang-tidy nightly on main instead.

Takeaways

Fifteen patterns were in post 1. Seven tools enforce them here:

The stack is not one big decision. It’s a series of layered defaults:

• At the source-code level: use intrinsics when you need specific codegen; use [[likely]]/[[unlikely]] only on cold paths with non-trivial bodies.
• At the build level: -O2 -march=x86-64-v3 -Wall -Wextra -Werror -Wpessimizing-move -Wrange-loop-construct for every production build; -ffast-math only on isolated compute kernels where you own the inputs.
• At the CI level: .clang-tidy with performance-* and modernize-* as errors; a clang-tidy workflow that blocks PRs.

None of the three rings alone catches everything. The builtins need humans to type them. The flags affect the whole binary, for better or worse. The clang-tidy checks have false positives that need disabling. Layered, they give you a codebase that tends toward the fast path without every author needing to remember every rule.

References

• Post 1: C++ Low-Latency Patterns, Benchmarked — the 15 patterns these tools enforce.
• GCC: Other Built-in Functions Provided by GCC — the canonical builtin reference.
• LLVM clang-tidy Checks — every check, every option.
• x86-64 microarchitecture levels (Wikipedia) — the v2/v3/v4 feature matrix.
• Okade, P., and Baker, K. (2025). C++ Performance Tips: Cutting Down on Unnecessary Objects. CppCon 2025 — the source of the warning-flag list in §2.5.
• Lakos, J. Large-Scale C++ Software Design — the long-form case for -fno-exceptions, -fno-rtti, and the rest of the no-cost-abstractions discipline.

The full source for all seven benchmarks (plus the Dockerfile and the make_godbolt_nb.sh + make_godbolt_nb_flags.sh scripts) lives in the same hft-perf-benchmarks/ directory as post 1. Build the image once, docker run -v $(pwd):/work hft-nb bash -c "for f in 16_*.cpp 17_*.cpp 18_*.cpp 19_*.cpp 22_*.cpp; do g++ -O2 -std=c++23 \$f -pthread -o \${f%.cpp}.out && ./\${f%.cpp}.out; done", and you will get a per-tool scoreboard for your CPU.
